Garmin GPS 19x NMEA 2000

Tutorial Videos

Questions and Answers (Q&As)

Popular Accessories

What's Included In The Box?

• GPS 19x NMEA 2000
• Pole mount
• Surface mount
• Under deck mount
• NMEA 2000 backbone/drop cable (6 m)
• NMEA 2000 T-connector
• Documentation

Product Information

Gallery of Customer Images

Customer Reviews

Family Series

Alternative Models

Manufacturer Description

The highly accurate GPS 19x NMEA 2000 position receiver/antenna provides 10 Hz update rates for position, velocity and time data. It offers high-sensitivity reception and enhanced position acquisition to the Garmin family of marine multifunctional displays (MFD), instrument display and autopilots.

Delivers Reliable Location Data

This 32-channel receiver is capable of tracking multiple global navigation satellite systems, including GPS, GLONASS, Galileo¹ and QZSS¹. Since more satellites are visible, it can provide more accurate fixes in challenging conditions. With its enhanced position, heading and speed accuracy delivered 10 times more often than other receivers/antennas, it provides smoother drawing of your position on the chartplotter/MFD at higher speeds.

WAAS-capable, it can determine your precise location to within 3 m (9.84 ft).

Observable Advantages

Compared to units with slower update rates, the GPS 19x offers dramatic improvement when used at low speeds. Position and course information from slower units can jitter and swing considerably at speeds below 1 mph. The GPS 19x provides a consistent and smooth heading which is especially important when trying to hit a specific waypoint or mark.

The GPS 19x also reflects the true boat heading smoothly and accurately. This is especially evident when coming out of turns. And, the GPS 19x eliminates position skipping that can occur at low speeds and when turning the boat in an arc. The GPS 19x maintains a smooth position throughout the turn².

Built for Versatility

Part of the Garmin marine instrument family, the GPS 19x NMEA 2000 is built to withstand the elements. This waterproof (IPX7) sensor can be pole mounted or flush mounted. It also can be attached to the underside of many fiberglass decks for added ease of installation.

¹Supported when available. A software update may be required.

²The GPSMAP 6000 series, 7000 series and newer chartplotters have been optimized to fully use the 10 Hz information from the GPS 19x.

Features and Tips

GPS 19x NMEA 2000 features

• Highly accurate position receivers that provide up to 10Hz position, velocity and time data via NMEA 2000
• Can support multiple GNSS – including GPS, GLONASS, Galileo2, QZSS2
• 32 Channel receiver – since more overhead satellites are now visible, users will see more accurate fixes in challenging conditions
• Provides true position and heading data smoothly and accurately– especially evident when coming out of turns
• Extraordinary low speed performance
• Provides a consistent and smooth heading – key when trying to hit a specific waypoint or mark
• When compared to units with slower update rates, the GPS 19x eliminates position skipping that can occur at low speeds
• GPS 19x HVS can be configured to have a 1 Hz or 5 Hz update rate to help support specific installations
• Dimensions (diameter x height): 3.6” x 1.9”
• Weight: 7.1 oz
• Case: Fully gasketed, high-impact plastic alloy; waterproof to IEC 60529 IPX7 standards
• Power input source: GPS 19x NMEA 2000 9-16 Vdc, unregulated
• Input current: 40 mA at 12 Vdc
