Garmin GPSMAP 4010

Tutorial Videos

Questions and Answers (Q&As)

What's Included In The Box?

• GPSMAP 4010
• GPS 17x NMEA 2000
• Bail mount and knobs
• Protective front cover
• Top and bottom snap covers
• Video cable assembly
• Power cable assembly
• NMEA 0183 cable
• NMEA 2000 drop cable
• NMEA 2000 10 m backbone cable
• NMEA 2000 power cable
• NMEA 2000 T-connector & terminator kit
• Flush mount hardware
• Flush mount gasket
• Marine grommet kit
• Owner’s manual on disk
• Quick reference guide
• Installation instructions

Product Information

User Manual

Gallery of Customer Images

Customer Reviews

Manufacturer Description

This mid-sized 4000 series chartplotter fills the gap between the smaller GPSMAP 4008 and the wider GPSMAP 4012. Like its counterparts, the 4010 serves as your all-in-one "nerve center" for the Garmin Marine Network. This chartplotter has crisp, video-quality resolution on a 10.4" diagonal SVGA display as well as a worldwide, satellite-enhanced basemap. By connecting to the Garmin Marine Network, you can add sonar, radar and weather. For even more enhanced features, you can add the optional BlueChart g2 Vision card.

View Detailed Graphics and Video
The 4010 features a worldwide basemap with high-quality satellite images in place of more traditional maps. And for more detail, you can add maps easily with the SD card slot without having to connect to a computer. The 4010's high-speed processor draws maps quickly, and its simple, intuitive interface makes navigating easy. To keep tabs on your engine room or other areas of your boat, you can also connect a live video feed with the 4010's video input option.

Add Extras with BlueChart g2 Vision
With optional BlueChart g2 Vision SD cards, you can add a whole new dimension of exceptional features to your chartplotter.

• Choose to view 3D map information at "mariner's eye view" above the waterline or "fish-eye view" below the water.
• High-resolution satellite images and aerial photographs help you orient yourself in unfamiliar areas.
• Auto Guidance technology searches through all relevant charts to create a route you can actually follow - one that avoids obstacles, shallow water, buoys and other obstructions.

Features and Tips

GPSMAP 4010 features

• Garmin radar compatible: yes

• Garmin sonar compatible: yes

• CANetâ„¢ compatible: no

• Garmin Marine Networkâ„¢ compatible: yes

• Supports AIS (tracks target ships' position): yes

• Supports DSC (displays position data from DSC capable VHF radio): yes

• Audible alarms: yes

• Tide tables: yes

• Hunt/fish calendar: no

• Sun and moon information: yes

• 3D map view: yes (with optional BlueChart g2 Vision card)

• Auto Guidance: yes (with optional BlueChart g2 Vision card)

• Automatic routing (turn by turn routing on roads): no

• XM WX Weather & Radio for U.S. compatible: yes

• Voice prompts (e.g. "Turn right in 500 ft."): no

• Remote control: yes (optional)

• Headphone jack/audio line-out: no

• Audio/video input/output: yes

• Portable: no

• Automotive/motorcycle-friendly: no

• Additional: Interface Inputs/Outputs: 3 built-in network ports, 4 NMEA input (supports NMEA 2000), 2 NMEA output, 2 video inputs for onboard cameras, 1 SVGA PC monitor

• Unit dimensions, WxHxD: 13.4" x 8.9" x 4.2" (34 x 22.6 x 10.7 cm)

• Display size, WxH: 9.7" x 7.3", 10.4" diagonal (24.6 x 18.5 cm, 26.4 cm diagonal)

• Display resolution, WxH: 800 x 600 pixels

• Display type: SVGA display

• Weight: 7.8 lb (3.5 kg)

• Battery: none

• Battery life: none

• Waterproof: yes (IPX7)

• Antenna: external

• NMEA input/output: NMEA 0183, NMEA 2000


• Basemap: yes

• Preloaded maps: no

• Ability to add maps: yes

• Built-in memory: none (cannot load maps to internal memory)

• Accepts data cards: SD card slot (BlueChart g2 Vision cards sold separately)

• Waypoints/favorites: 1,500

• Routes: 20

• Track log: 10,000 points; 20 saved tracks
