GISTEQ PhotoTrackr Plus GPS for Nikon

What's Included In The Box?

The GISTEQ PhotoTrackr Plus for Nikon ships with the following items included:

• GPS Adapter
• Bluetooth GPS Receiver
• Travel Pouch
• Quick Start Guide
• AC Charger
• Car Charger

Product Information

GISTEQ PhotoTrackr Plus for Nikon Family Series

Manufacturer Description

TIPS: Photo Geotagging is the process of adding geographical identification metadata to photographs. These data usually consist of latitude and longitude coordinates, as well as altitude, and place names. Photo Geocoding refers to the process of adding non-coordinate based geographical identifiers, such as a street address, to the photographs.

Compatible Cameras:

Nikon D90, D3100, D5000, and D7000, D200, D300, D300s, D700, D2X, D2Xs, D2Hs, D3, D3X, D3s and Fujifilm S5Pro.

Features

• Geotags your photos as you shoot - seemless integration with the supported cameras
• No software needed
• Plug and play
• Built-in memory - capable of geotagging photos with last known location if satelite fix is not available
• Auto and quick connection
• Compact and reliable
• Light weight and low power consumption.
• High sensitivity GPS
• RAW photo support
• Built-in Rechargeable Li-ion Battery
• Power saving with vibration sensor in GPS receiver
• GPS receiver battery life: 44+ hours under continous use

Compare to Nikon original GPS unit
	PhotoTrackr Plus	NIKON GP-1
Usage Illustration
GPS Warm-up Time	No waiting time: GPS is not affected by camera on/off (external GPS)	GPS warm-up every time the camera is turned on/off
Average power consumption	Consumes less battery power/GPS does not consume camera battery power (40mW)	180mW
Occupied Space	Use 10-pin terminal only	Occupy accessory shoe (flash mount space)
Last Known Position	Saves the last known position to geotag photos even satellite signal is not available	Not able to geotag photos when satellite signal is not available
Wiring	Bluetooth Connection - no wiring with GPS, more flexible	Wired GPS
Dimensions(WHD)	smaller size(26x18x12mm)	45x25x55mm
Cable	No	Yes
Power supply	Camera Battery
On/off switch	No
Power On	Power on camera
Power off	Turn off both camera and GPS receiver, or disconnect adapter	Disconnect adapter
When camera is off	Device continue to receive GPS data
Interface for Remote switch	Optional Canon RS60 E3	Optional MC-DC2
GPS Receiver	High sensitivity GPS: tracking channel: 44	Tracking channels: 18
Acquisition times	Cold/Warm/Hot start time: 29/10/1 seconds (on average)	Cold/Hot start time: 45/5 seconds
Update rate	1 Hz
Data format	NMEA version 2.3 (compatible with version 3.01)

HOW IT WORKS: (3 simple steps)

• Connect GPS adapter to your Nikon camera’s 10-pin remote terminal.
• Setup camera GPS settings. Click here to see detailed instructions.
• Start taking pictures and GPS data will be recorded directly into photographs.

Connect GPS adapter to the camera

Nikon DSLR with GPS adapter will receive GPS data from the GPS receiver and embed GPS info into the photo's EXIF data

GPS receiver will transfer GPS data wirelessly to the camera via the Bluetooth connetion

Features & Tips

PhotoTrackr Plus for Nikon features

• 10-pin terminal for GPS adapter
• Connection for remote switch
• Battery Life: Operation Time: 30+ hours in continuous mode
• 44 channels satellite tracking
• Cold/Warm/Hot start time: 29/10/1 seconds (on average)
• DATUM: WGS84
• SBAS (WAAS, EGNOS) support
• Superior sensitivity: -160dBm tracking
• Update Rate: 1 Hz
• Support standard NMEA-0183 at 38400 bps baud rate
• Dimension: 3.03 (L) x 1.81 (W) x 0.77 (H) inch
• Weight: 3 oz including battery
• Accuracy:
  • Position: <3m 2d-RMS; DGPS: 2.5m
  • Velocity: 0.1m/sec
  • Acceleration: 0.1m/s2; DGPS: 0.05m/s2
• Frequency: L1, 1575.42MHz
• C/A Code: 1.023MHz chip rate
• Antenna (internal): Built-in low noise patch antenna
