Not yet rated. Email:
 Print:
See more RAM Mount items. |
| |
| List Price: |
$87.30 |
| Our Price: |
$65.95 (and this item ships for $3.49) |
| You Save: |
$21.35 (24%) |
Availability: |
In Stock.
Ships tomorrow, May 29. |
|
| |
| Model: |
RAM Mount Chrome Garmin GPSMAP 600 Series Screw Down Mount |
| Part No: |
RAM-B-139-G4-CHU |
| Condition: |
Brand New, Lifetime Manufacturer Warranty (max 3 years on electronics & lenses) |
|
| Price Match: |
Get an Instant Price Match in about 5 minutes (during business hours). |
|
Learn More with our Instructional Videos |
| » See our list of GPS City videos. Visit our Youtube channel. |
RAM Mount Plate: Overview (RAM-B-347)
(4,910 views) |
RAM AMPS Hole Pattern: Explained
(8,035 views) |
Check out our
channel. | | |
|
What's Included In The Box? |
The RAM Mount Chrome Garmin GPSMAP 600 Series Screw Down Mount ships with the following items included: |
Product Information |
| Manufacturer: |
National Products, Inc |
Category: |
All Purpose Mounts |
Type: |
GPS Mounts |
| Model: |
RAM-B-139-G4-CHU |
SKU: |
RACB139G4 |
UPC: |
|
| Announced: |
March 27, 2009 |
First Shipped: |
March 27, 2009 |
Weight: |
0.644 lbs. |
Manufacturer Description |
The RAM-B-139-G4-CH Garmin GPSMAP 620 and GPSMAP 640 Series RAM Mount is a Chrome Plated Marine Grade Aluminum Mount with a Flat Surface Screw Down Base and GPSMAP 600 Series Cradle Plate. The mount is designed with a RAM 1 inch diameter patented rubber ball and socket system that has adjustment point at the cradle and base. With a twist of the arm knob, you can move the Garmin GPSMAP 620 and GPSMAP 640 Series mount to your optimum viewing position.
Garmin GPS Mount Options:To help ensure you have the Garmin GPSMAP 620 and GPSMAP 640 Mount you require, take a look at the list of available RAM Garmin GPS mounts on the RAM-B-347-G4 Series of Garmin GPSMAP 620 and GPSMAP 640 Cradles and Mounts Page. Here you can select from suction cup GPS mounts, flat surface screw down GPS mounts, GPS car mounts, non skid weighted GPS mounts and more bundled with the RAM-B-347-G4 Garmin GPSMAP 620 and GPSMAP 640 Series Hardware and Plate.
Garmin GPS Mount Cradle Plate Design: The RAM Aluminum Rectangular Plate has a four hole AMPS pattern which will connect to the back of the Garmin GPSMAP 620 and GPSMAP 640 series cradle. The Garmin GPSMAP 600 series cradle is included with the purchase of the GPS unit. The RAM Mount Plate and hardware connect to the following Garmin units:
- Garmin GPSMAP 620 GPS
- Garmin GPSMAP 640 GPS
All cables can stay connected to the unit while in the RAM cradle.
Connection Hardware Included: The plate includes four sets of nuts and bolts (RAM-S-G4) to connect the plate to your required cradle.
Garmin GPS Mount Arm Design: The RAM-B-201CH Chrome Plated Marine Grade Aluminum Dual Socket Arm is a 1 inch B size Ball Socket Arm with open socket ends. The arm is 3.0 inches long between socket centers and is finished with a Chrome Plating. The side of the arm includes a tightening knob which allows you to open and close the socket ends. For a layout of the dimensions RAM-B-201 arm, take a closer look with the RAM-B-201 Design Drawings (pdf file).
Garmin GPS Mount Base Design: The RAM-B-202CH Chrome Plated Marine Grade Aluminum Screw Down Plate has a 1.0 inch diameter Rubber Ball connected at right angles to a 2.5 inch diameter Plate. The plate has pre-drilled holes in the base plate, including the universal AMPS hole pattern. For a layout of the hole spacing and 1.0 inch rubber ball location, take a closer look with the RAM-B-202 Design Drawings (pdf file).
Mount Base Mounting Solutions:Mounting hardware is NOT included with the purchase of the RAM-B-202. A semi-permanent solution for mounting this base is by using the RAM double sided adhesive disk (RAM-202PSA). The disk will hold the RAM-B-202 base in many different locations without screws.
|
Features & Tips |
Here is a listing we have put together of some of the common Chrome Garmin GPSMAP 600 Series Screw Down Mount features,
along with a few user tips that you may find of help for this particular item. | - Warranty: Manufacturer's Life Time Warranty.
- Cradle Design: Aluminum cradle plate with hardware for GPSMAP 620 and GPSMAP 640 Series.
- Cradle Material: Black Powder Coated Marine Grade Aluminum.
- Mount Material: Chrome Plated Marine Grade Aluminum.
- Mount Ball Size: RAM 1 inch Solid Rubber Ball.
- Pivot Point Design: RAM Patented 1 inch Rubber Ball and Socket Joint.
- Arm Type: RAM Arm with Dual 1 inch Sockets.
- Arm Length: Standard length of 3 inches between socket centers.
- Base Type: Round shaped 2.5 inch diameter plate designed to be bolted to a flat surface.
- Common Applications:
- Vehicle Mounts: Attaching to vehicle dash.
- Motorcycle Mounts: Attaching to small ledge or flat surface on motorcycle console.
|
