RAM Mount Garmin eTrex Color Series on Motorcycle Brake Mount

Overview



Reviews



Videos



Specifications



Forum


RAM Mount Garmin eTrex Color Series on Motorcycle Brake Mount
Available Videos
Watch the Garmin eTrex Cradle: In Use (RAM-HOL-GA16) Video Watch the Diamond Plate: Overview (RAM-B-238U) Video Watch the Medium Arm: Overview (RAM-B-201U) Video
Watch the Motorcycle Kit Reservoir: On Suzuki (RAM-B-309-7) Video Watch the Motorcycle Kit U-Bolt: On Suzuki (RAM-B-309-7) Video Watch the Motorcycle Base Kit: Overview (RAM-B-309-7) Video
Watch the Motorcycle Kit Mount: Overview (RAM-B-174U) Video

(based on 2 reviews). Add your own review.
See more RAM Mount products.

List Price: $36.92 USD
Our Price: $31.95 USD
You Save:  $4.97 USD (13%)

In Stock! Ships by 3PM PST on Monday, November 23.

This item is Brand New with a Lifetime Warranty (excluding electronic or lense components).

Found a lower price? Please let us know!

 Canadian Customers! Save on shipping fees, customs, duty, and PST! Buy this item from Canada's original on-line GPS store, gpscity.ca, located in Calgary, Alberta.

RAM Mount Garmin eTrex Color Series on Motorcycle Brake Mount Product Detail
  • Category: RAM Mount RAM Mounts
  • Manufacturer: RAM Mount
  • Model No: RAM-B-174-GA16U
  • SKU: RAMB174GA16
  • Weight: 0.725 lbs
Share and Save
  Email   Print    Twitter  Digg  Facebook  MySpace  Google Bookmarks  del.icio.us  Fark  Technorati  reddit  StumbleUpon  Mixx  Furl  Yahoo! Bookmarks  Windows Live Favorites  Ask MyStuff  Slashdot  Propeller  Newsvine  myAOL Favorites


Need Assistance? Contact us on

from 8AM - 5PM PST, Mon-Fri
or Call us at 1-866-GPS-CITY
(1-866-477-2489)
from 8AM - 5PM PST, Mon-Fri


What's Included With The RAM Mount Garmin eTrex Color Series on Motorcycle Brake Mount?
The RAM Mount Garmin eTrex Color Series on Motorcycle Brake Mount ships with the following items included:


RAM Mount Garmin eTrex Color Series on Motorcycle Brake Mount Description
The RAM-B-174-GA16 RAM Mount Marine Grade Aluminum Motorcycle Brake/Clutch Base Mount consists of the 1 inch diameter RAM ball and socket system with RAM Plastic Cradle for the Garmin eTrex Color Series, including the Garmin eTrex Vista Cx, Legend Cx and Venture Cx.

Note: For the eTrex Series Mono, you will require the RAM Motorcycle Brake/Clutch Mount for the Garmin eTrex Series Mono (RAM-B-174-GA5)

Mount Cradle Design:

The RAM-HOL-GA16 RAM Mount High Strength Plastic Cradle is designed to hold the Garmin eTrex Color Screen Series, including the following GPS units,
  • Garmin eTrex Summit HC
  • Garmin eTrex Venture C
  • Garmin eTrex Venture Cx
  • Garmin eTrex Venture HC
  • Garmin eTrex Legend C
  • Garmin eTrex Legend Cx
  • Garmin eTrex Legend HCx
  • Garmin eTrex Vista C
  • Garmin eTrex Vista Cx
  • Garmin eTrex Vista HCx
All cables can stay connected to the unit while in the RAM cradle.

The Garmin eTrex, eTrex Camo, eTrex Summit, eTrex Venture, eTrex Legend and eTrex Vista WILL NOT fit this cradle. These units require the RAM-HOL-GA5 eTrex (non-color screen) cradle and mounts.

Mount Arm Design:
The RAM Mount Dual Socket Arm (RAM-B-201) is a B Size 1 inch Ball Dual Socket Arm, made of Marine Grade Aluminum. The arm is 3 inches long between socket centers and is finished with a Black Powder Coating. The side of the arm includes a tightening knob which allows you to open and close the socket ends.

Mount Base Design:

The RAM-B-309-1 RAM Mount Powder Coated Marine Grade Aluminum Clutch/Brake Motorcycle Mount Base includes a 1 inch diameter Rubber Ball and a hexagonal opening for the connection of an optional secondary RAM-B-309-3 Rubber 1 inch diameter ball. Included with this base is both standard and metric mounting bolts.

The base connects to the left or right side of your handlebar clutch/brake reservoir on the Honda Goldwing and other select Motorcycles. To see if this base will work with your motorcycle, check the hole spacing of the base against your clutch/brake reservoir. The holes centers have a minimum width of 0.94 inches and a maximum of 1.58 inches and can be viewed in the design drawing below.

RAM E-Drawings and In Use Pictures:

To understand more about the RAM-B-309-1 Motorcycle Mount Base hole spacing and ball layout and location, check out the design drawing below. The second image shows the RAM-B-309-1 in use and how the base mounts to the clutch/brake reservoir.
RAM-B-309-1 e-drawing
RAM-B-309 Base e-drawing
RAM-B-309-1 in use connection
RAM-B-309 Base In Use
