RAM Mount Garmin GPSMAP 60 Series on Motorcycle Brake Mount Product Detail
Call us at 1-866-GPS-CITY (1-866-477-2489) from 8AM - 5PM PST, Mon-Fri
What's Included With The RAM Mount Garmin GPSMAP 60 Series on Motorcycle Brake Mount? The RAM Mount Garmin GPSMAP 60 Series on Motorcycle Brake Mount ships with the following items included:
RAM Mount Garmin GPSMAP 60 Series on Motorcycle Brake Mount Description The RAM-B-174-GA12 RAM Mount Marine Grade Aluminum Motorcycle Brake/Clutch Base Mount consists of the 1 inch diameter RAM ball and socket system with RAM Plastic Cradle for the Garmin GPS 60, GPSMAP 60, GPSMAP 60C, GPSMAP 60CS and GPSMAP 60Cx, GPSMAP 60CSx
Mount Cradle Design:
The RAM-HOL-GA12 RAM Mount High Strength Plastic Cradle is designed to hold the Garmin GPS 60 and GPSMAP 60 Series, including the following GPS units,
Garmin Astro 220 Series
Garmin GPS 60
Garmin GPSMAP 60
Garmin GPSMAP 60C
Garmin GPSMAP 60CS
Garmin GPSMAP 60Cx
Garmin GPSMAP 60CSx
All cables can stay connected to the unit while in the RAM cradle.
Mount Arm Design: The RAM Mount Dual Socket Arm (RAM-B-201) is a B Size 1 inch Ball Dual Socket Arm, made of Marine Grade Aluminum. The arm is 3 inches long between socket centers and is finished with a Black Powder Coating. The side of the arm includes a tightening knob which allows you to open and close the socket ends.
Mount Base Design:
The RAM-B-309-1 RAM Mount Powder Coated Marine Grade Aluminum Clutch/Brake Motorcycle Mount Base includes a 1 inch diameter Rubber Ball and a hexagonal opening for the connection of an optional secondary RAM-B-309-3 Rubber 1 inch diameter ball. Included with this base is both standard and metric mounting bolts.
The base connects to the left or right side of your handlebar clutch/brake reservoir on the Honda Goldwing and other select Motorcycles. To see if this base will work with your motorcycle, check the hole spacing of the base against your clutch/brake reservoir. The holes centers have a minimum width of 0.94 inches and a maximum of 1.58 inches and can be viewed in the design drawing below.
RAM E-Drawings and In Use Pictures:
To understand more about the RAM-B-309-1 Motorcycle Mount Base hole spacing and ball layout and location, check out the design drawing below. The second image shows the RAM-B-309-1 in use and how the base mounts to the clutch/brake reservoir.
