Customer Images
Share your images and get a
free gpscity.com t-shirt!
|
Not yet rated. Email:
 Print:
See more RAM Mount items. |
| |
| List Price: |
$273.62 |
| Our Price: |
$233.95 |
| You Save: |
$39.67 (14%) |
Availability: |
In Stock.
Ships tomorrow, May 29. |
|
| |
| Model: |
RAM Mount Large Plate Post Mount RAM-E-111U-247-25 |
| Part No: |
RAM-E-111U-247-25 |
| Condition: |
Brand New, Lifetime Manufacturer Warranty (max 3 years on electronics & lenses) |
|
| Price Match: |
Get an Instant Price Match in about 5 minutes (during business hours). |
|
What's Included In The Box? |
The RAM Mount Large Plate Post Mount RAM-E-111U-247-25 ships with the following items included: |
Product Information |
| Manufacturer: |
National Products, Inc |
Category: |
All Purpose Mounts |
Type: |
Plate Mounts |
| Model: |
RAM-E-111U-247-25 |
SKU: |
RAME111-247-25 |
UPC: |
|
| Announced: |
January 18, 2006 |
First Shipped: |
August 29, 2006 |
Weight: |
11.225 lbs. |
RAM Mount Large Plate Post Mount RAM-E-111U-247-25 Family Series |
RAM Mount Large Plate Post Mount RAM-E-111U-247-25 |
RAM Mount Large Plate Post Mount Short RAM-E-111U-D-247-25 | | | | |
|
Manufacturer Description |
The RAM-E-111-247-25 RAM Mount Marine Grade Aluminum Mount, with Square Rail Clamp Base, consists of the 3.37 inch diameter ball and socket system with RAM Universal Rectangular 11 x 3 inch Plate. This mount is designed to be a universal mounting solution for large and heavy electronic devices, including large Marine GPS. The hole pattern found on the rectangular plate will connect to a large variety of third party cradle, gimbal brackets and mounts.
Rectangular Universal Mount End Plate Design:The RAM-E-111B RAM Mount Marine Grade Aluminum Universal Rectangular Plate has a 3.37 inch diameter rubber ball connected at right angles to a 11 x 3 inch plate. The plate has some pre-drilled holes which may match up to your electronic devices and mounts, or you can drill new holes of your own. For a layout of the hole spacing and 3.37 inch rubber ball location, take a closer look with the RAM-E-111B Design Drawings (pdf file).
Rectangular Universal Mount Arm Design:The RAM-E-201 RAM Mount Dual Socket Arm is a 3.37 inch D size Ball Socket Arm made of Marine Grade Aluminum. The arm is 10.31 inches long between socket centers and is finished with a Black Powder Coating. The side of the arm includes a tightening knob which allows you to open and close the socket ends. For a layout of the dimensions RAM-E-201 arm, take a closer look with the RAM-E-201 Design Drawings (pdf file).
Rectangular Universal Mount Base Design:The RAM-E-247-25 RAM Mount Powder Coated Marine Grade Aluminum Square Rail Base has a 3.37 inch diameter Rubber Ball designed to sit at right angles to the mounting rail. The square clamp consists of two aluminum plates that are compressed together by two bolts connected at each edge. The aluminum plates are 2.875 inches wide between hole centers, and the bolts are 3.0 inches long. The Base is designed to clamp to a square rail up to 2.5 inches square. For a layout of the hole spacing and 3.37 inch rubber ball location, take a closer look with the RAM-E-247-25 Design Drawings (pdf file).
Rectangular Universal Mount Options:To help ensure you have the Rectangular Universal Electronics and Marine Mount you require, take a look at the list of available RAM Universal Plate mounts on the Rectangular Universal Electronic Mount Page. Here you can select from flat surface screw down mounts, different length arm mounts, pole/post mounts and more bundled with the RAM-E-111B Rectangular Universal Electronics and Marine Plate.
|
Features & Tips |
Here is a listing we have put together of some of the common Large Plate Post Mount RAM-E-111U-247-25 features,
along with a few user tips that you may find of help for this particular item. | - Warranty: Manufacturer's Life Time Warranty
- Cradle Design: Rectangular Plate to connect large and heavy electronics including Marine GPS
- Cradle Material: Black Powder Coated Marine Grade Aluminum Plate
- Mount Material: Black Powder Coated Marine Grade Aluminum
- Mount Ball Size: RAM 2.25 inch Solid Rubber Ball
- Pivot Point Design: RAM Patented RAM 3.37 inch Rubber Ball and Socket Joint
- Arm Type: RAM Arm with Dual 3.37 inch Sockets
- Arm Length: Standard length of 10.31 inches between socket centers
- Base Type: Universal Square Pipe Base with Aluminum Plate Clamps
|
