Customer Images
Share your images and get a
free gpscity.com t-shirt!
|
Not yet rated. Email:
 Print:
See more RAM Mount items. |
| |
| List Price: |
$216.93 |
| Our Price: |
$177.95 |
| You Save: |
$38.98 (18%) |
Availability: |
In Stock.
Ships tomorrow, May 29. |
|
| |
| Model: |
RAM Mount Large Plate Surface Mount Short RAM-E-111U-D |
| Part No: |
RAM-E-111U-D |
| Condition: |
Brand New, Lifetime Manufacturer Warranty (max 3 years on electronics & lenses) |
|
| Price Match: |
Get an Instant Price Match in about 5 minutes (during business hours). |
|
What's Included In The Box? |
The RAM Mount Large Plate Surface Mount Short RAM-E-111U-D ships with the following items included: |
Product Information |
| Manufacturer: |
National Products, Inc |
Category: |
All Purpose Mounts |
Type: |
Plate Mounts |
| Model: |
RAM-E-111U-D |
SKU: |
RAME111D |
UPC: |
793442903663 |
| Announced: |
January 18, 2006 |
First Shipped: |
August 29, 2006 |
Weight: |
8.157 lbs. |
RAM Mount Large Plate Surface Mount Short RAM-E-111U-D Family Series |
RAM Mount Large Plate Surface Mount RAM-E-111U |
RAM Mount Large Plate Surface Mount Short RAM-E-111U-D | | | | |
|
Manufacturer Description |
The RAM-E-111-D RAM Mount Marine Grade Aluminum Mount, with Short Arm and Screw Down Base, consists of the 3.37 inch diameter ball and socket system with RAM Universal Rectangular 11 x 3 inch Plate. This mount is designed to be a universal mounting solution for large and heavy electronic devices, including large Marine GPS. The hole pattern found on the rectangular plate will connect to a large variety of third party cradle, gimbal brackets and mounts.
Rectangular Universal Mount End Plate Design:The RAM-E-111B RAM Mount Marine Grade Aluminum Universal Rectangular Plate has a 3.37 inch diameter rubber ball connected at right angles to a 11 x 3 inch plate. The plate has some pre-drilled holes which may match up to your electronic devices and mounts, or you can drill new holes of your own. For a layout of the hole spacing and 3.37 inch rubber ball location, take a closer look with the RAM-E-111B Design Drawings (pdf file).
Rectangular Universal Mount Arm Design:The RAM-E-201-D RAM Mount Dual Socket Arm is a 3.37 inch D size Ball Socket Arm made of Marine Grade Aluminum. The arm is approximately 5.0 inches long between socket centers and is finished with a Black Powder Coating. The side of the arm includes a tightening knob which allows you to open and close the socket ends.
Rectangular Universal Mount Base Design:The RAM-E-202 RAM Mount Marine Grade Aluminum Screw Down Plate has a 3.37 inch diameter Rubber Ball connected at right angles to a 3.68 inch diameter Plate. The plate has pre-drilled holes in the base plate, including two holes at 180 degrees and three holes at 120 degrees. For a layout of the RAM-E-202 plate dimensions, take a closer look with the RAM-E-202 Design Drawings (pdf file).
Note: Mounting hardware is NOT included with the purchase of the RAM-E-202.
Rectangular Universal Mount Options:To help ensure you have the Rectangular Universal Electronics and Marine Mount you require, take a look at the list of available RAM Universal Plate mounts on the Rectangular Universal Electronic Mount Page. Here you can select from flat surface screw down mounts, different length arm mounts, pole/post mounts and more bundled with the RAM-E-111B Rectangular Universal Electronics and Marine Plate.
|
Features & Tips |
Here is a listing we have put together of some of the common Large Plate Surface Mount Short RAM-E-111U-D features,
along with a few user tips that you may find of help for this particular item. | - Warranty: Manufacturer's Life Time Warranty
- Cradle Design: Rectangular Plate to connect large and heavy electronics including Marine GPS
- Cradle Material: Black Powder Coated Marine Grade Aluminum Plate
- Mount Material: Black Powder Coated Marine Grade Aluminum
- Mount Ball Size: RAM 2.25 inch Solid Rubber Ball
- Pivot Point Design: RAM Patented RAM 3.37 inch Rubber Ball and Socket Joint
- Arm Type: RAM Arm with Dual 3.37 inch Sockets
- Arm Length: Short length of approximately 5.0 inches between socket centers
- Base Type: Round 3.68 inch diameter Plate design to be bolted to a flat surface
|
