The RAM-B-174-G3 RAM Mount Marine Grade Aluminum Motorcycle Brake/Clutch Base Mount consists of the 1 inch diameter RAM ball and socket system with RAM Aluminum Plate with Mounting Hardware for the Garmin StreetPilot 7xxx Series, includnig the Garmin StreetPilot 7200 and 7500.
Mount Cradle Design:
 The RAM Aluminum 2.5 inch diameter Round Plate has a four hole AMPS pattern which will connect to the back of the Garmin StreetPilot 7xxx series cradle. The Garmin StreetPilot 7xxx series cradle is included with the purchase of the GPS unit. The RAM Mount Plate and hardware connect to the following Garmin units:
- Garmin StreetPilot 7200 GPS
- Garmin StreetPilot 7500 GPS
All cables can stay connected to the unit while in the RAM cradle.
Connection Hardware Included: The plate includes four sets of nuts and bolts (RAM-S-G3) to connect the plate to your required cradle.
Mount Arm Design:
 The RAM Mount Dual Socket Arm (RAM-B-201) is a B Size 1 inch Ball Dual Socket Arm, made of Marine Grade Aluminum. The arm is 3 inches long between socket centers and is finished with a Black Powder Coating. The side of the arm includes a tightening knob which allows you to open and close the socket ends.
Mount Base Design:
 The RAM-B-309-7 RAM Mount Motorcycle Kit Base can mount to either the clutch/ brake reservoir or directly to a round handle bar rail. The base is constructed of marine grade aluminum with an integrated 1 inch diameter rubber ball, hardware for rail mounting and both standard and metric mounting bolts for motorcycle reservoir mounting. The zinc coated metal u-bolt and nuts included are designed it fit on most motorcycle round handlebars, or any circular rail or pipe with diameter from 1/2 to 1.25 inches.
The base connects to the left or right side of your handlebar clutch/brake reservoir on the Honda Goldwing and other select motorcycles or you can connect directly to your handlebars with the u-bolt hardware. To see if this base will work with your motorcycle, check the hole spacing of the base against your clutch/brake reservoir. The holes centers have a minimum width of 0.94 inches and a maximum of 1.58 inches.
|
