RAM Mount TomTom GO 520 720 920 Series Motorcycle Kit Mount Product Detail
Category: RAM Mount RAM Mounts
Manufacturer: RAM Mount
Model No: RAM-B-174-7-TO6
SKU: RAMB174-7TO6
Weight: 0.744 lbs
Need Assistance?
Contact us on from 8AM - 5PM PST, Mon-Fri
or
Call us at 1-866-GPS-CITY (1-866-477-2489) from 8AM - 5PM PST, Mon-Fri
What's Included With The RAM Mount TomTom GO 520 720 920 Series Motorcycle Kit Mount? The RAM Mount TomTom GO 520 720 920 Series Motorcycle Kit Mount ships with the following items included:
RAM Mount TomTom GO 520 720 920 Series Motorcycle Kit Mount Description The RAM-B-174-7-TO6 TomTom GO 520/520T, GO 720/720T and GO 920/920T Series Motorcycle Kit RAM Mount is a Marine Grade Aluminum Mount with a Motorcycle Brake/Clutch Reservoir PLUS U-Bolt Base and RAM Custom Plastic Cradle. The mount is designed with a RAM 1 inch diameter patented rubber ball and socket system that has adjustment point at the cradle and base. With a twist of the arm knob, you can move the TomTom GO 520/520T, GO 720/720T and GO 920/920T Series mount to your optimum viewing position.
Garmin GPS Mount Options:
To help ensure you have the TomTom GO 720 and GPS 920 Mount you require, take a look at the list of available RAM TomTom GPS mounts on the TomTom GO 720 and GPS 920 Mount Page. Here you can select from suction cup GPS mounts, flat surface screw down GPS mounts, GPS car mounts, non skid weighted GPS mounts and more bundled with the RAM-HOL-TO6 TomTom GO 720 and GPS 920 Cradle.
Garmin GPS Mount Cradle Design:
The RAM-HOL-TO6 RAM Mount High Strength Plastic Cradle is designed to hold the following TomTom GPS units,
TomTom GO 520
TomTom GO 520T
TomTom GO 720
TomTom GO 720T
TomTom GO 920
TomTom GO 920T
All cables can stay connected to the unit while in the RAM cradle.
Garmin GPS Mount Cradle Plate:
The RAM-B-238 Marine Grade Aluminum Diamond Plate is designed to connected to the back of the mount cradle. The diamond plate has a 1.0 inch diameter rubber ball connected at right angles to the plate, which connects directly to the 1 inch arm socket. The cradle includes the required hardware to connect the plate to the cradle. For a layout of the hole spacing and 1.0 inch rubber ball location, take a closer look with the RAM-B-238 Design Drawings (pdf file).
Garmin GPS Mount Arm Design:
The RAM-B-201 RAM Mount Marine Grade Aluminum Dual Socket Arm is a 1 inch B size Ball Socket Arm with open socket ends. The arm is 3.0 inches long between socket centers and is finished with a Black Powder Coating. The side of the arm includes a tightening knob which allows you to open and close the socket ends. For a layout of the dimensions RAM-B-201 arm, take a closer look with the RAM-B-201 Design Drawings (pdf file).
Garmin GPS Mount Base Design:
The RAM-B-309-7 RAM Mount Motorcycle Kit Base can mount to either the clutch/ brake reservoir or directly to a round handle bar rail. The base is constructed of marine grade aluminum with an integrated 1 inch diameter rubber ball, hardware for rail mounting and both standard and metric mounting bolts for motorcycle reservoir mounting. The zinc coated metal u-bolt and nuts included are designed it fit on most motorcycle round handlebars, or any circular rail or pipe with diameter from 1/2 to 1.25 inches.
The base connects to the left or right side of your handlebar clutch/brake reservoir on the Honda Goldwing and other select motorcycles or you can connect directly to your handlebars with the u-bolt hardware. To see if this base will work with your motorcycle, check the hole spacing of the base against your clutch/brake reservoir. The holes centers have a minimum width of 0.94 inches and a maximum of 1.58 inches.
RAM E-Drawings and In Use Pictures:
To understand more about the RAM-B-309-7 Motorcycle Mount Base hole spacing and ball layout and location, check out the design drawing below of the RAM-B-309-1 (Note: the hexagonal hole shown in the design drawings is not included on the RAM-B-309-7). The second image shows the RAM-B-309-8 in use showing how the RAM-B-309 base series mounts to the clutch/brake reservoir.
