Customer Images
Share your images and get a
free gpscity.com t-shirt!
|
Customer Rating:  (based on 3 reviews). Email:
 Print:
100% of our reviewers recommend this item. See more RAM Mount items. |
| |
| List Price: |
$59.60 |
| Our Price: |
$38.95 (and this item ships for $3.49) |
| You Save: |
$20.65 (35%) |
Availability: |
In Stock.
Ships today, February 15. |
|
| |
|
|
| Model: |
RAM Mount Universal Mini Screw Down Mount RAM-B-102-UN1U |
| Part No: |
RAM-B-102-UN1U |
| Condition: |
Brand New, Lifetime Manufacturer Warranty (max 3 years on electronics & lenses) |
|
| Price Match: |
Get an Instant Price Match in about 5 minutes (during business hours). |
|
| Learn More with our Instructional Videos (More GPS City videos.
Visit our Youtube channel.) |
RAM Universal Grip Cradle: In Use (RAM-HOL-UN1)
(2,045 views) |
RAM Universal Grip Cradle: Dimensions (RAM-HOL-UN1)
(889 views) |
RAM Universal Cradle with Mobile Phone (RAM-HOL-UN1)
(754 views) |
RAM Diamond Plate: Overview (RAM-B-238U)
(20,301 views) |
RAM AMPS Hole Pattern: Explained
(6,618 views) |
|
| What's Included In The Box? |
The RAM Mount Universal Mini Screw Down Mount RAM-B-102-UN1U ships with the following items included: |
| Product Information |
| Manufacturer: |
National Products, Inc |
Category: |
All Purpose Mounts |
Type: |
Universal Mounts |
| Model: |
RAM-B-102-UN1U |
SKU: |
RAMB102UN1 |
UPC: |
793442907746 |
| Announced: |
February 1, 2008 |
First Shipped: |
February 1, 2008 |
Weight: |
0.651 lbs. |
| RAM Mount Universal Mini Screw Down Mount RAM-B-102-UN1U Description |
The RAM-B-102-UN1U Universal Clamping Series RAM Mount is a Marine Grade Aluminum Mount with a Small Flat Surface Screw Down Base and RAM Universal Plastic Cradle. The mount is designed with a RAM 1 inch diameter patented rubber ball and socket system that has adjustment point at the cradle and base. With a twist of the arm knob, you can move the Universal Clamping Cradle Series mount to your optimum viewing position.
Universal Mount Cradle Design:
 The RAM-HOL-UN1 Small RAM Plastic Side Clamping Cradle is designed to hold a large amount of different kinds of cell phones and electronic devices.
Using the Cradle:
This cradle has padded locking side clamps that close tightly on the item you want to hold. To release the clamp hold, simply press the button found at the bottom left side of the cradle which will spring the clamps open. At the base of the cradle are two small supports to hold the bottom of the item securely in the cradle. This RAM universal side clamping cradle is designed to be used in a closed cabin, low vibration environment. This system is not recommended as a motorcycle mount.
Universal Cradle Dimensions:
- Minimum Grip Width: 1.5''
- Maximum Grip Width: 2.6''
- Side Clamp Height: 1.88''
- Side Clamp Depth: 1.13''
- Cradle Spine Height: 3.68''
- Cradle Spine Width: 2.0''
NOTE: The top of the cradle is open, so the items in the cradle can be larger than the height of the cradle.
Universal Mount Cradle Plate:
 The RAM-B-238 Marine Grade Aluminum Diamond Plate is designed to connected to the back of the mount cradle. The diamond plate has a 1.0 inch diameter rubber ball connected at right angles to the plate, which connects directly to the 1 inch arm socket. The cradle includes the required hardware to connect the plate to the cradle. For a layout of the hole spacing and 1.0 inch rubber ball location, take a closer look with the RAM-B-238 Design Drawings (pdf file).
Universal Mount Arm Design:
 The RAM-B-201 RAM Mount Marine Grade Aluminum Dual Socket Arm is a 1 inch B size Ball Socket Arm with open socket ends. The arm is 3.0 inches long between socket centers and is finished with a Black Powder Coating. The side of the arm includes a tightening knob which allows you to open and close the socket ends. For a layout of the dimensions RAM-B-201 arm, take a closer look with the RAM-B-201 Design Drawings (pdf file).
Universal Mount Base Design:
The RAM-B-238 Powder Coated Marine Grade Aluminum Universal Base Plate has a 1.0 inch diameter Rubber Ball connected at right angles to a 1 1/4 x 2 1/2 inch Diamond Plate. The plate has two pre-drilled holes positioned at either tip of the diamond plate. This is the perfect mounting solution when you need to mount your device with a small foot print. Great as a motorcycle mount when mounting on a small ledge or vehicle mount when you want to bolt inside your vehicle. This base needs to be bolted or screwed to the mounting surface. Mounting hardware is not included. For a layout of the hole spacing and 1.0 inch rubber ball location, take a closer look with the RAM-B-238 Design Drawings (pdf file).
Universal Mount Options:
 To help ensure you have the Universal Mount you require, take a look at the list of available RAM universal small clamping cradle mounts on the RAM-HOL-UN1 Series of small universal cradles and mounts Page. Here you can select from suction cup universal mounts, flat surface screw down universal mounts, universal car mounts, non skid weighted universal mounts and more bundled with the RAM-HOL-UN1 Universal Series Cradle. Alternatively, you can review the complete list of RAM universal cradles and mounts.
|
| RAM Mount Universal Mini Screw Down Mount RAM-B-102-UN1U Features & Tips |
Here is a listing we have put together of some of the common Universal Mini Screw Down Mount RAM-B-102-UN1U features,
along with a few user tips that you may find of help for this particular item. | - Warranty: Manufacturer's Lifetime Warranty.
- Cradle Design: Universal Side Clamping Cradle for Cell Phones, GPS, iPod, Music Players and more.
- Cradle Material: Black High Strength Composite Plastic.
- Mount Material: Black Powder Coated Marine Grade Aluminum.
- Mount Ball Size: RAM 1 inch Solid Rubber Ball.
- Pivot Point Design: RAM Patented 1 inch Rubber Ball and Socket Joint.
- Arm Type: RAM Arm with Dual 1 inch Sockets.
- Arm Length: Standard length of 3 inches between socket centers.
- Base Type: Diamond shape plate design to be bolted to a flat surface.
- Common Applications:
- Vehicle Mounts: Attaching to vehicle dash.
- Motorcycle Mounts: Attaching to small ledge or flat surface on motorcycle console.
- Laptop Mounts: Attaching to the side of a RAM Laptop Tray.
|
